The Baja Designs LP6 lights fit perfectly with our HD Chase Light mount.

The LP6 Pro stands as a 6-inch powerhouse, delivering a total of 11,225 lumens and a 200-degree spread of usable LED light through our dedicated Integrated Peripheral Technology (IPT). For optimal performance, the LP6 integrates Direct Ducted Cooling (DDC) technology, allowing efficient air circulation over the rear heat sinks. Featuring colored daytime running light, low power, and high-power modes, the LP6 effortlessly caters to all your lighting needs.

Available in various patterns, the LP6 Pro suits diverse preferences. The Driving/Combo pattern offers maximum trail coverage with a blend of driving (42 degrees) and spot (8 degrees) optics for both near-field and distance applications. The Spot pattern, with its longer and narrower 8-degree beam focus, illuminates further down the trail or road, ideal for use with additional wide cornering or driving/combo auxiliary lights in Lighting Zones 4 & 5.

WIRING HARNESS SOLD SEPARATELY!

LIGHTS SOLD INDIVIDUALLY!

Satisfaction Guarantee – 30-Day Money Back Guarantee

Limited Lifetime Warranty – Complete Purchase Protection

uService – Replaceable Lenses And Optics

ClearView – All The Light, Right Where You Need It

MoistureBlock – Waterproof, Rain Proof, Submersible

CopperDrive – Safely Driving LEDs at 100%

5000K Daylight – Less Driver Fatigue, Natural Color

Specifications

Lens Color	Clear
Lens Material	Hardcoated Polycarbonate
Light Quantity	1
Lighting Modes	High Beam/Low Beam/Day-Time Running Backlighting
Lighting Quantity	6
Lighting Technology	LED
Lighting Type	Forward Projecting
Mounting Hardware Included	Yes
Mounting Hardware Material	Stainless Steel
Overvoltage Protection	Built-In
Product Type	LP6 Pro LED Light Pod
Secondary Amperage Rating (A)	1.000
Secondary Brightness (Lumens)	1972
Secondary Light Quantity	4 LEDs
Secondary Lighting Technology	LED
Secondary Lighting Type	Integrated Peripheral Technology (IPT)
Secondary Wattage (W)	15
Terminal Connector	DT06-4S Deutsch
Terminal Type	Mating Connector
Universal or Specific	Universal
Wattage (W)	103.500
Wiring Harness Included	No
Amperage Rating (A)	7.500
Average Rated Life (hr.)	49,930
Backlight Amperage Rating (A)	0.300
Backlight Wattage (W)	4.140
Beam Pattern	Spot
Bezel Material	Powder Coat Cast Aluminum
Brightness (Lumens)	11225
Description	Spot; Clear
Housing Color	Black
Housing Material	Powder Coat Cast Aluminum

Standards & Compliance

Standards/Compliance (Durability)	Exceeds MIL-STD810G (Mil-Spec Testing)
Standards/Compliance (Impact Resistance)	IK10 Compliant (Mechanical Impact Testing)
Standards/Compliance (Water Resistance)	IP69K (Waterproof up to 9ft & Pressure Washable)

Dimensions

Depth (in.)	3.200
Height (in.)	6.500
Length (in.)	6.500
Weight (lbs.)	4.200
